Automatic Fly Knife Plastic Pipe Making & Cutting Machine
- Inquiry Email: Kevinxu@xmjw.ltd
- Product Code: pipe1215499507
- Availability: In Stock
Automatic fly Knife cutter plastic PVC PE PPR pipe making machine Plumbing pipe cutter Pipe tubing cutter
Product Description
| Corrugated Pipe Cutting Machine | |
| Display | 7 Inch Man-Machine Interface |
| MOQ | 1 Set |
| Customized | MOQ 1 Set For Customized Version |
| Function |
1, corrugated pipe /PVC pipe/heat shrink pipe, such as thin-wall pipe fixed length cut and cut; Section function: It can be opened at any position, any length, continuous section |
| Processing Range | 4-32mm |
| Cutting Length | 1mm---999999.99mm |
| Cutting Tolerance | Within 0.003*L (L=Cutting Length) |
| Maximum Diameter Allowed Through | Φ35 |
| Production Rate | 100000pcs/hour(Depends on the length of the tube, the size) |
| Drive Mode | 10-wheel drive; Servo Motor Optional |
| Feeding System | Belt Feeding, No embossing or scratches on the pipe |
| Lifting Operation Mode | Digital Adjustment of pressure wheel/roller height |
| Split Power Mode | Servo Motor |
| Split Speed Adjustment | Touch Screen Stepless Speed Regulation |
| Split Adjustment Menthod | Screw Rod+ Stepper Motor Digital Adjustment |
| Split Position | Any Position, Any Length, Continuous Section |
| Power Supply | AC220v 50/60Hz; Optional: 110v 50/60Hz |
| Air Source | NO Air Source |
| Dimension | 68*57*43cm |
| N.W | 85kg |
| Key Words | Pipe Cutting Machine, PVC tube cutting machine,Automatic bellows cutting machine |
Feature:
1, Optional: MES system, Internet of Things system, fixed-point inkjet function, mid-stripping function, external auxiliary equipment alarm;
2, User-friendly system, intuitive operation via 7-inch color touch screen;
3, Modular interface, convenient for linking accessories and peripheral equipment;
4, Modular design, future upgradeable;
5, A variety of additional options can customize the system. Special pipe processing can be customized
| Brand Name | STM |
| Cutting length | 1-999999.99mm |
| Cutting tolerance | 0.003*L |
| Electrical connection | AC220V 50/60Hz |
| Maximum cutting diameter | 35 |
| Place of Origin | Henan;China;Henan;China |
| Size | 68*57*43mm |
| Use | Cutting |
| Useage | Cutting |
| Voltage | AC220V 50/60Hz |
| Weight | 70kg |
